Measuring conditions: CIE 10° standard observer; CIE D65 light source
Measuring range: L*:1-100
Repeatability: Standard deviation within ΔE*ab*below 0.08(testing condition: measure the white calibration board 80 times for average)
- Chromaticity Value: L*a*b,L*c*h, ΔE*ab,XYZ,Yxy, Relative RGB,color difference ΔE*ab, ΔE*ch
- Whiteness:Hunter Whiteness, Ganz Whiteness;
- Yellow: YI
Storage: 100 sets of standard samples; up to 100 under each standard sample
Measuring time: About 0.5 seconds
Measuring light source: LED
languages: Chinese, English
Power: Four AA1.5V Alkaline battery or nickel-metal hydride batterys; Exclusive DC5V adapter
port: USB2.0 printer
Device sensor exports Japan and processing chip is from USA, which guarantee the optical signal transfer accuracy and electrical signal stability. Display accuracy reaches 0.01, repeated test accuracy ΔE deviation value is below 0.08
2. Multiple color space display color values : L*a*b,L*c*h,Yxy
Being the most commonly used testing device, our colorimeter with built-in color display indicators transformation program, which makes our device could be used for color testing in many different industries. And it do not need convert the measurement data by manual which greatly improve the work efficiency.
3. Can Measurement Index of Whiteness and Yellowness
Index of Whiteness: Hunter and Gantz
Index of Yellowness: YI
4. Ergonomic Design
Instrument designs according to human palm so we could test data for long time with it. Superior leather design increases the friction in case of fingers sliding.
5. Free Color Management Software
Real-time display of pass or fail, generate testing report, save the color values, suitable for enterprise to evaluate color and management the color value.
6. Establish L*a*b* by manually
The standard samples can be manually set to meet the color difference test if there is no sample in hand.
7. Large store memory
The device could store 100 standard sample groups and every sample group could store 100 sample data.
8. Average Measurement Values
Test different points on sample and get the average value. It is widely used for color control whose color is not uniform.
9. CS-260 colorimeter could match the color with the build-in color card to get the most similar color number. It will be more convenient for the worker to check.รับประกันสินค้า 1 ปี
