DCC025 : บูตเตอร์แรงดันไฟกระแสตรง DC-DC Boost Voltage Converter 8-32V to 12-35V 72W

220 บาท
มีสินค้าอยู่ 14
บูตเตอร์แรงดันไฟกระแสตรง DC-DC Boost Voltage Converter 8-32V to 12-35V 72W >> เช็คสต๊อคสินค้า <<
Feature:
  • Module Name: 72W boost module
  • Module properties: non-isolated module
  • Input Voltage: 8-32V
  • Output voltage :12-35V   (adjustable)
  • Output current: 3A (12V turn to 24V) ; 5A(12V turn to 19V)  (exceed 4A please enhance heat dissipation)
  • Output power: 72W (natural cooling), 100W (enhance heat dissipation )
  • Output ripple: less than 50mV ,20M bandwidth
  • Conversion efficiency: efficiency 92%(12 turn to 24V 3A ),  efficiency 93%(12 turn to 19V 3A)
  • Operating temperature: Industrial grade -40°c to +85°c (ambient temperature exceeds 40 degrees, reduce power or plus fan)
  • Full load temperature rise: 45°c
  • No-load current: typical 30mA
  • Load Regulation: ± 0.5%
  • Voltage Regulation: ± 0.5%
  • Dynamic response speed: 5% 200uS
  • Short circuit protection: None (please enter retrofitting fuse or protective circuit)
  • Input reverse polarity protection: None (If need please install diode at input port )
  • Wiring: Terminals, Needn't solder, V-IN input, V-OUT output
  • Module size: 65mm x 51mm
Some Applications:
  • DIY an output adjustable vehicle power supply, 12V input,14-35V output (adjustable)
  • Universal Car Laptop power. 12V Input , the output can be adjusted to the laptop operating voltage
  • Boost charger,such as, for the 24V battery
  • Power supply for electronic equipment
  • Front of a system power supply:when the input voltage is 10-18V and the system board requires about 24V output(high power)
Note:
  • Input voltage must be less than the output voltage, for example,when 24V output ,the range of input is 8-24V
  • 12V 1 meter wire(1.5 m2),if longer than 1 meter,please use larger wire .
  • When needs to work on high-power, high-temperature or plus shell  please install a fan, be sure the  temperature of module heat sink not exceed 80°c
  • 12V battery discharge voltage should not be lower than 10.5V, Li-ion battery used in tandem (single 3.7V) discharge voltage should not be lower than 2.7V
รับประกันสินค้า 7 วัน
