DCB005 : เซอร์กิตเบรกเกอร์ อุปกรณ์ป้องกันไฟฟ้า เบรกเกอร์ป้องกันไฟช๊อต2P 32A DC 440V Circuit breaker MCB

160 บาท
มีสินค้าอยู่ 6
เซอร์กิตเบรกเกอร์ อุปกรณ์ป้องกันไฟฟ้า เบรกเกอร์ป้องกันไฟช๊อต2P 32A DC 440V Circuit breaker MCB

>> เช็คสต๊อคสินค้า <<

Specification:

  • TOBIZ-63 Series DC Miniature Circuit Breaker,apply to rating current 63A or less,
  • Direct current rating voltage 220V and 440V.
  • It is mainly used for the overloading and short circuit protection in DC distribution system Equipment and electric equipment.
  • It can be widely used in electric, post, traffic, mining enterprise and different kinds of fields.
  • our products in the case grade rating voltage is highest compared to the same products.
  • Products according IEC60898-1, GB14048.2 standard.

Characteristic TOBIZ-63 DC circuit breaker is made up of case, operation mechanism, thermal overloading trip, electromagnetic trip contact system, arc system etc. It has overloading and short circuit protection, unique-design structure and strong permanent magnetism arc system make the product has 6KA short circuit capability. Long mechanical life over 20000 times and beautiful shape. It can be connected with din rail named TH35-7.5 standard stainless type and has the below personality: the handle is designed on the top of the front, people will feel safe and comfortable when operating. When connecting, pay attention to "+, -" poles; The power goes in from the top and comes out from the underside which is applied with power entrance character. Convenient for installation and saving cables. It is used for 440V circuit 3 poles circuit breaker to connect front loop for two poles serial connection. B Curve (3-5In) protection for people and big length cables in TN and IT systems C Curve (5-10In) protection for resistive and inductive loads with low inrush current. D Curve (10-14In) protection for circuits which supply loads with high inrush current at the circuit closing (LV/LV transformers, breakdown lamps)



Crust grade rating current Imm(A)

Pole

Rating voltage(V)

Rating current In(A)

Rated limit short circuit capability

Instantaneous trip type

Breaking current Icu(A)

Time (ms)

63A

1

DC ~125V

1. 2. 3. 4. 5. 6. 10. 15. 16. 20. 25. 32. 40. 50. 63

10000

10

B. C. D

2

DC ~440V

6000

3

DC ~800V

4

DC ~1000V





รับประกันสินค้า 1 เดือน

ข้อมูลจำเพาะ

Information on technical characteristics, the delivery set, the country of manufacture and the appearance of the goods is for reference only and is based on the latest information available at the time of publication.
